Comparitive study between normal tension glaucoma and primary open-angle glaucoma

Bharathi N; Shwetha Kumari C; Ranjitha C Sadananda; Madhura M Khanapur; Neetu N; Sowmya Shree B V*

Introduction

Glaucoma is progressive optic neuropathy that causes characteristic changes of the optic nerve and visual field in relation to intraocular pressure (IOP).1

Primary open angle glaucoma (POAG) has normal-appearing anterior chamber angle, increased intraocular pressure (IOP) with glaucomatous optic nerve damage and characteristic visual field loss.2 NTG differs from POAG only in that the IOP is consistently <21mmHg.

This study aims at determining the differences in functional and structural deficits in NTG and POA and rate of progression of NTG into POAG.

Materials and Methods

Patients attending the department of Ophthalmology at Minto Ophthalmic Hospital, screened during the period Nov 2016 – Aug 2019 & patients fulfilling the criteria like Gonioscopy showing open-angles, Optic nerve cupping and corresponding visual field defects were taken into study. Diurnal IOP was recorded and subjects divided into two groups based on the readings. Patients with <21mmHg IOP (56) were put in NTG group and those of >21mmHg (56) were grouped into POAG group. Written informed consent was taken. Ethical committee clearance was obtained.

Ocular hypertensives, patients with Primary angle-closure glaucoma, Secondary glaucoma, Corneal disorders, Posterior-segment pathologies and Non-glaucomatous optic neuropathy were excluded from the study.

Detailed history was taken from all the patients and ocular examination of both eyes was done, which included visual acuity with Snellen’s chart, Slit-lamp biomicroscopy, IOP was measured using Goldmann applanation tonometer, Indirect Gonioscopy using Goldmann three mirror lens, optic disc evaluation was done with slit-lamp biomicroscopy using by 78 D, Time domain OCT (Zeiss Cirrus HD OCT) done to asses RNFL parameters, Pachymetry was done and Visual fields assessment were done using Zeiss Humphrey field- analyser. Each patient was followed-up till 34 months.

Results

Statistical software namely SAS 9.2, SPSS 15.0, Stata 10.1, MedCalc 9.0.1, Systat 12.0 and R environment ver.2.11.1 are used for the analysis of the data. Student t test, Chi-square test / Fisher Exact test were used to study the significance of study parameters. Leven’s test was performed to assess the homogeneity of Variance. P-value of 0.05 was considered as significant.

Mean age was found to be 58.96 yrs in NTG and 55.07 in POAG. NTG was more common in females (58.9%), whereas POAG was more common in males (73.2%). Systemic involvement was more common in NTG (71.4%) with diabetes in 42.9% (24), hypertension in 25% (14), bronchial asthma and migraine in 1.8% each (1).

There was no significant difference in CDR between two groups.

Temporal (32.1%) and inferior (39.3%) NRR thinning was more common in NTG, whereas bipolar thinning (57.1%) was more common in POAG. Retinal Nerve Fiber Layer (RNFL) was significantly thinner in POAG in all four quadrants.

There were no significant changes in MD and PSD values of Visual fields (VF) between NTG and POAG. NTG showed localized field defects which were closer to centre of fixation, while it was diffuse and denser in POAG.

Table 1

Demographic comparision between the two groups of patients

Character	NTG	POAG	P value
Mean age	58.96 Yrs	55.07 Yrs	0.002
Sex	58.9% (33) Female 41.1% (23) Male	26.8% (15) Female 73.2% (41) Male	0.001
Systemic involvement	71.4% (40)	50% (28)	0.020

Table 2

Mean disc CDR comparison of patients in two groups of patients

Mean Disc CDR	NTG	POAG
Right Eye	0.69±0.11	0.73±0.09
Left Eye	0.71±0.11	0.76±0.11

[i] Chi-square test/Fisher Exact test

[ii] CDR – Cup Disc Ratio

Table 3

Disc NRR distribution of patients in two groups of patients studied

	NTG			POAG
Disc NRR	Right Eye	Left Eye	Disc NRR	Right Eye	Left Eye
WNL	8(14.3%)	4(7.1%)	WNL	1(1.8%)	1(1.8%)
Temporal thinning	17(30.4%)	18(32.1%)	Temporal thinning	13(23.2%)	4(7.1%)
Bipolar thinning	6(10.7%)	8(14.3%)	Bipolar thinning	23(41.1%)	32(57.1%)
IR Thinning	21(37.5%)	22(39.3%)	IR Thinning	3(5.4%)	0(0%)
Superior thinning	1(1.8%)	2(3.6%)	Superior thinning	16(28.6%)	16(28.6%)
Superior notch	2(3.6%)	1(1.8%)	Superior notch	0(0%)	0(0%)
All rims thinned	1(1.8%)	1(1.8%)	All rims thinned	0(0%)	0(0%)
Inferior thinning	0(0%)	0(0%)	Inferior thinning	0(0%)	3(5.4%)
P value		<0.001** Right Eye		<0.001** Left Eye

[i] NRR – Neuroretinal Rim

[ii] Chi-square test/Fisher Exact test

Table 4

Distribution of RNFL thickness on OCT

RNFL	NTG	POAG	P value
Superior Quadrant	82.76±16.9	63.73±12.59	<0.001**
Inferior quadrant	88.05±14.55	59.98±7.14	<0.001**
Nasal quadrant	54.66±8.18	46.04±6.80	<0.001**
Temporal quadrant	54.11±5.58	45.09±5.96	<0.001**
Average thickness	69.90±6.61	53.71±6.31	<0.001**

[i] RNFL – Retinal Nerve Fiber Layer

[ii] OCT – Optical Coherence Tomography

[iii] Student t test (two-tailed, independent)

Figure 1

RNFL OCT showing bilateral inferior rim thinning

https://s3-us-west-2.amazonaws.com/typeset-prod-media-server/e8e98493-bc13-46bf-a9ba-5d6cc301c2a6image1.jpeg

Table 5

Visual fields- distribution of patients in two groups of patients studied

Visual Fields	NTG	POAG	P value
Right Eye
MD (dB)	-17.14±7.25	-18.79±8.08	0.261
Mean PSD	9.27±3.50	11.42±3.85	0.003**
Left Eye
MD (dB)	-16.22±6.88	-17.56±6.75	0.303
Mean PSD	9.38±2.80	11.07±3.52	0.006**

[i] MD – mean deviation; PSD – pattern standard deviation

On follow up, two patients of NTG had raised IOP and were converted to POAG. No significant changes were observed in VF and RNFL on follow up.

Discussion

NTG & POAG are two extremes of pressure-independent & dependent glaucomatous optic nerve damage. NTG is a condition with glaucomatous optic disc, visual field changes, an open-angle with normal range of IOP. IOP is a part of the pathogenic process in NTG & factors other than IOP may contribute to optic nerve damage by making the nerve susceptible to damage at lower IOP levels.

Figure 2

Gonisoscopic picture of open angle. All four structures are visible. (SL – Schwalbe’s line, TM – trabecular meshwork, SS – Scleral spur, CBB – ciliary body band)

https://s3-us-west-2.amazonaws.com/typeset-prod-media-server/e8e98493-bc13-46bf-a9ba-5d6cc301c2a6image2.jpeg

In our study, it was found that majority of the patients i.e., 48.2% in NTG and 62.5% in POAG, belonged to the age group between 51 and 60 years (mean age of 58.96 yrs in NTG and 55.07 yrs in POAG). NTG was found to be more common in females i.e., 58.9% (33 patients) and POAG more common in males i.e., 73.2% (41 patients).

The optic disc CDR & NRR was examined between NTG & POAG. There was no significant difference in CDR between two groups whereas in disc NRR inferior & temporal rim thinning was more common in NTG. While bipolar thinning & superior rim thinning was more common in POAG.

In our study, it was found that systemic association for NTG (40%) was more common than POAG (28%). This is similar to a study done by Kristy G et al, in which 38% of NTG patients were associated with Migraine, Raynaud’s and hypotension, while 42% of NTG were associated with cardiovascular disease.3 The optic disc drance hemorrhage was found in NTG (9%) patients, unlike POAG & it was found to be associated with Diabetes mellitus & Hypertension.

In our study, the Mean RNFL thickness in superior quadrant is 85.82 ± 15.84 (NTG), 64.18 ± 14.42 (POAG); Inferior quadrant 86.64 ± 16.10 (NTG), 60.55 ± 8.26 (POAG); Nasal quadrant 54.29 ± 8.38 (NTG), 46.27 ± 6.93 (POAG) and Temporal quadrant 53.32 ± 5.98 (NTG), 45.38 ± 6.17 (POAG). Average thickness was 70.02 ± 6.14 (NTG) & 54.09 ± 6.84 (POAG). RNFL thickness by OCT gives an objective & quantitative assessment of glaucomatous structural loss.

Mean RNFL values by OCT of subjects in different studies.

Table 6

Superior quadrant

Study	NTG	POAG	OHT	GS	Normal
This study	82.76 ± 16.9	63.73 ± 12.59	-		-
Satyaprakash S et al 4	77.8 ± 30.58	65.45 ± 27.86	-	106.75 ± 16.47

[i] RNFL – Retinal Nerve Fibre Layer

[ii]

[iii] Mean superior quadrant RNFL thickness in NTG and POAG was comparable to Satyaprakash S et al. 4

Table 7

Inferior quadrant

Study	NTG	POAG	OHT	GS	Normal
This study	88.05 ± 14.55	59.98 ± 7.14	-		-
Satyaprakash S et al 4	92.6 ± 30.42	65.68 ± 32.89	-	103.62 ± 16.47	-

[i] Mean inferior quadrant RNFL thickness of NTG and POAG was comparable to Satyaprakash S et al.4

Table 8

Nasal quadrant

Study	NTG	POAG	OHT	GS	Normal
This study	54.66±5.58	46.04±6.80	-	-	-
Satyaprakash S et al4	49.6±13.99	44.91±23.79	-	63.95±11.12	-

[i] Mean nasal quadrant RNFL thickness of NTG was comparable with Satyaprakash S et al. POAG was comparable with Satyaprakash S et al.4

Table 9

Temporal quadrant

Study	NTG	POAG	OHT	GS	Normal
This study	54.11±5.58	45.09±5.96	-	-	-
Satyaprakash S et al	54.7±12.99	42.84±18.86	-	57±11.77	-

[i] OHT – Ocular Hypertension

[ii] GS – Glaucoma suspect

[iii]

[iv] Mean temporal quadrant RNFL thickness of NTG and POAG was comparable with Satyaprakash S et al.4

Table 10

Average RNFL Thickness

Study	NTG	POAG	OHT	GS	Normal
This study	69.90±6.61	53.71±6.31	-	-	-
Satyaprakash S et al 4	70.1±17.81	55.26±19.75	-	82.29±10.66	-

[i] OHT – Ocular Hypertension

[ii] GS – Glaucoma suspect

[iii]

[iv] Mean average RNFL thickness of NTG and POAG was comparable with Satyaprakash S et al.4

We compared the mean deviation (MD) & pattern standard deviation (PSD) in visual fields between NTG & POAG. There was no significant difference between the two, similar to previous studies. We found that field loss was near centre of fixation in NTG, compared to POAG, which was diffuse.

Table 11

Mean MD (dB) in visual fields of subjects in different studies

Study	NTG	POAG	HTG	PXFG
This study			-	-
Michele Iester et al 5	-6.31±13.2		-7.69±5.02	-
Oraorn Thonginnetra et al6	-3.61±2.08		-4.47±2.60	-

[i] MD – Mean Deviation

[ii] HTG – High Tension Glaucoma

[iii] PXFG – Pseudoexfoliative Glaucoma

The mean MD of our study was not comparable with other studies.

Table 12

Mean PSD in visual fields of subjects in different studies

Study	NTG	POAG
This study
Michele Iester et al 5	7.08±4.16	7.52±3.38
Oraorn Thonginnetra et al 6	2.82±3.54	4.98±2.46

[i] PSD – Pattern Standard Deviation

The mean PSD of NTG was comparable to Michele Lester et al while that of POAG was not comparable to previous studies.

Patients were followed up for 34 months, where IOP, Visual fields (VF) and OCT for RNFL was done. We found no significant difference in VF and RNFL, but two patients of NTG were converted to POAG due to raised IOP on follow up.

The results of this study were comparable with the variables of other similar studies. Hence, our study plays a significant role in assessing the parameters which may be noticed in NTG and POAG, which can assess the risk and reduce the further progression of the disease. Further medical and surgical management can also be planned for the same.

Source of Funding

None.

Conflict of Interest

None.
